Name: Lead Free PPTCs PolySwitch Devices 16V For Rechargeable Cells / Battery Strap
Brand: Yantai Rongfan Electronic Technology Co., Ltd
SKU: SRS175
Price: 0.20 USD
Availability: InStock

Detail Information

Lead-Free:	Yes	Resettable Hold Current:	0.7A - 3A
Maximum Voltage Rating:	16V	Maximum Resistance:	0.01Ω-0.2Ω
Halogen-Free:	Yes	Agency Approvals:	UL, CSA, TUV
Maximum Operating Temperature:	-40°C To +85°C	Current Rating:	0.7A - 10A
Highlight:	Lead Free PPTCs PolySwitch Devices , PPTCs PolySwitch Devices 16V , Rechargeable Cells PPTCs PolySwitch Devices

Product Description

16V PolySwitch Lead Free Battery Strap PPTCs For Rechargeable Cells/Battery Strap PPTCs PolySwitch Devices

Battery strap devices provide reliable, non-cycling protection

against overcharging and short circuits events for rechargeable

battery cells where resettable protection is desired.

Lead Free PPTCs PolySwitch Devices 16V For Rechargeable Cells / Battery Strap 0

Figure1 Figure2

Electrical Characteristics Determined at 25 ℃

Part number	IH (A)	IT (A)	V max (V)	I max (A)	Pd max (W)	R min (Q)	R max (Q)	图号
SRS120	1.20	2.70	15	100	1.20	0.085	0.160	1
SRS120S	1.20	2.70	15	100	1.20	0.085	0.160	2
SRS175	1.75	3.80	15	100	1.50	0.040	0.090	1
SRS175S	1.75	3.80	15	100	1.50	0.040	0.090	2
SRS200	2.00	4.40	24	100	1.90	0.030	0.060	1
SRS350	3.50	6.30	24	100	2.50	0.017	0.031	1
SRS380	3.80	7.20	24	100	2.70	0.015	0.130	1
SRS420	4.20	7.60	24	100	2.90	0.012	0.024	1
SRS450	4.50	8.60	24	100	3.00	0.011	0.011	1

Product Dimensions(mm)

Part number	图号	A		B		C		D		E
Part number	图号	MIN	MAX	MIN	MAX	MIN	MAX	MIN	MAX	MIN	MAX
SRS120	1	19.9	22.1	4.9	5.2	0.6	1.0	5.5	7.5	3.9	4.1
SRS120S	2	19.9	22.1	4.9	5.2	0.6	1.0	5.5	7.5	3.9	4.1
SRS175	l	20.9	23.1	4.9	5.2	0.6	1.0	4.1	5.5	3.9	4.1
SRS175S	2	20.9	23.1	4.9	5.2	0.6	1.0	4.1	5.5	3.8	4.2
SRS200	1	21.3	23.4	10.2	11.0	0.5	1.1	5.0	7.6	4.8	5.4
SRS350	1	28.4	31.8	13.0	13.5	0.5	1.1	6.3	8.9	6.0	6.6
SRS380	1	29.0	32.0	13.0	13.5	0.5	1.1	6.3	8.9	6.0	6.6
SRS420	1	30.6	32.0	13.0	13.5	0.5	1.1	5.0	7.5	6.0	6.7
SRS450	1	30.6	33.0	13.0	13.5	0.5	1.1	5.0	7.5	6.0	6.7

Typical Time-to-Trip Curve at 25°C

A=SRS120 B=SRS175 C=SRS200 D=SRS350 E=SRS450

Time-to-Trip (s) Lead Free PPTCs PolySwitch Devices 16V For Rechargeable Cells / Battery Strap 1

Place of Origin:	China
Brand Name:	RFan
Certification:	UL.CE.TUV.ROHS
Model Number:	SRS175

Minimum Order Quantity:	1000
Price:	0.2-0.6
Packaging Details:	1000/Bag
Delivery Time:	5-7days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	2KK/M
